產品名稱：0530

產品詳情

產品參數

系列	型號	電感值(μH)	DCR(mΩ)	飽和電流(A)	溫升電流(A)	工作溫度(℃)	長(mm)	寬	高
HRTN0530	HRTN0530AR10Y	0.1	2.5	27	23	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR15Y	0.15	2.3	30	18	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR20Y	0.2	2.6	25	16	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR22M	0.22	3.7	21	15.5	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR25M	0.25	3.7	20	15	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR33M	0.33	4.3	18	14	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR47M	0.47	6.4	16	12	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR56M	0.56	8.0	15	10	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR68M	0.68	10	14	8.5	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530AR82M	0.82	11.5	12.5	8.0	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A1R0M	1.0	13	11	7.0	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A1R2M	1.2	14	11	6.5	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A1R5M	1.5	16	10	6.0	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A2R2M	2.2	25	9.0	5.5	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A3R2M	3.3	32	8.0	5.0	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A3R6M	3.6	46	7.0	4.9	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A4R7M	4.7	50	6.0	4.6	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A5R6M	5.6	55	4.5	4.25	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A6R8M	6.8	68	4.3	4.0	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A100M	10	110	3.50	2.75	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A150M	15	165	2.6	2.1	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A180M	18	195	2.3	2.0	-55~155	5.7	5.2	2.8
HRTN0530	HRTN0530A220M	22	220	1.9	1.7	-55~155	5.7	5.2	2.8
